Plate Compactor and Vibratory Asphalt/Soil Plate

7 HP 4500-Pound Compaction Force Plate Compactor, CARB Compliant


A must have tool for anyone working on walkways, patios, paver installations, landscaping or small asphalt projects. Powerful 212cc /7 HP engine delivers 4,496 lbs. of force at 5,400 blows per minute, increasing the density of loose granular soils, gravel, sand, crushed aggregate and other mediums into a sound, level foundation. This type of foundation extends the life of your project as it reduces water seepage, swelling and expansion. Our unique swing-over handle makes it easy to maneuver around the work area even in narrow, cramped spaces. Our engine features an angled combustion chamber (for more power per displacement), a pull recoil start and a low-oil shutdown to protect the engine. Vibration isolators between the welded steel plate and the engine reduce vibration, extending the engines life. High density foam in the handles also reduces vibration to the user. 1 Gal. fuel tank provides ample work time. Tough powder-coat finish keeps the product rust-free. 1-year limited warranty, 90 day commercial.


  • Powerful: 212cc engine is larger than most in its class, producing 4,496 lbs. of force at 5,400 blows per minute
  • Maneuverable with our unique swing-over handle and the compact 24 in. x 17-3/4 in. contoured edge plate
  • Fast travel speed productivity, single direction plate travels up to 82 ft. per minute
  • Vibration isolators between the welded steel plate and the engine reduce vibration extending the engines life
  • Easily transportable with lift handles at the plate, as well as central lifting/load bar
  • CARB compliant
  • Plate Width (in.): 18
  • Plate depth (in.): 24
  • Blows per Minute (BPM): 5400
  • Compacting Force (lb.): 4496
  • Engine Displacement (cc): 212
  • Engine Torque (ft.-lb.): 8.85
  • Engine Type: Four-Stroke OHV Single Cylinder with forced air cooling system
  • Fuel Tank Capacity: 1
  • Fuel Type: Gas
  • Horsepower (hp): 7
  • Start Type: Pull
  • Item Weight: 207lbs



Contact us and let us know about your next project.
